Brief Introduction

REL-MR-110DC/21-21AU/MS

Product type: Single relay, miniature power relay with plug-in connection with multi-layer gold-plated contacts.Electrical characteristicsInput Data: The input voltage is rated at 110V DC and the input voltage range is 71.5V DC to 272.8V DC. The drive is monostable and non-polarized, with a typical input current of 4.1mA, a typical response time of 7ms, a typical release time of 3ms, a coil resistance of 26600Ω±15% at 20°C, and a maximum power consumption of 0.45W at rated input voltage.Output data: 2 changeover contacts for contact switching type, single contact type for switching contact, contact material AgNi with hard gold plating. Under normal conditions, the maximum switching voltage is 30V AC, 36V DC, the minimum switching voltage is 100mV (at 10mA), the limiting continuous current and the maximum inrush current are both 50mA, the minimum switching current is 1mA (at 24V), and the maximum power rating (resistive load) is 1.2W (24V DC). When the gold plating layer is destroyed, the maximum switching voltage is 250V AC/DC, the minimum switching voltage is 5V (at 100mA), the limited continuous current is 8A, the maximum impulse current is 50A (20ms), and the minimum switching current is 10mA (at 5V), the maximum power rating value (resistance load) will change accordingly, such as 190W (24V DC), 85W (48V DC), 60W (60V DC), 44W (110V DC), etc., and the switching capacity is 2A (24V, DC13), 0.2A (110V, DC13), 0.2A (250V, DC13), etc.
