Brief Introduction

MDX61B0008-5A3-4-00

Basic parametersRated power: 0.75kW.Input parameters: rated voltage is 380 - 500V for three-phase AC and 50 - 60Hz for power supply.Output parameters: The power of the adapted motor is 0.75kW, the output capacity is about 1.5kVA, the output current is about 4.0A, and the output frequency range is usually 0 - 400Hz.Overload capacity: 150% overload operation for 60s, 175% overload operation for 2s.Degree of protection: IP20, suitable for indoor cleaning environment.Dimensions: 72.5mm wide, 317mm high, 260mm deep.Weight: Approx. 2.0kg.Control functionsControl mode: Support a variety of control methods, such as voltage vector control (VFC), current vector control (CFC), etc., to achieve high-precision control of the motor.Built-in functions: Integrated IPOS positioning and sequence control system, which can easily realize speed control, single-axis position control and other functions, and can also complete driving tasks such as positioning and curling through standardized control programs, and users can set parameters through wizards without complex programming.
